This is a digital content – includes two 3D model parts for 3D printing.
A download link will be provided to you at the confirmation page. Preview & Instructions is available here.
3D model for the uConsole Keyboard under layers. The content contains 2 parts:
- The 3D model to replace the current diffuser
- Trackball shim to stabilise the trackball module
Diffuser
- The diffuser mainly improves the responsiveness of keypresses
- After using permanent markers pens following the instruction, it will improve the backlight balances, but does not eliminate it completely.
Instructions and guides can be found here.
3D Printing recommendation:
- Clear or translucent 95A TPU
- 0.4 nozzle
- 0.08 layer height
- Best with flat printing bed, but any other should work
If you would like to order a printed models & shipped to you, please don’t hesitate to contact me.
Support & Liability
DIY Disclaimer: This is a hobbyist project for a hackable device. The seller is not liable for any damages to the uConsole or its components resulting from the printing, assembly, or installation process. Proceed at your own risk.
Model Support: I provide full support for the functional aspects of the 3D model, specifically regarding key press responsiveness and mechanical fit.
Aesthetics for Lighting: Because backlight balancing is highly subjective and depends on your specific printing materials/settings, it is considered experimental and comes with limited support.
License is limited for Personal Use.
